Facilities

Thermal Science Lab:

pic3Centrifugal Pump System for fluid mechanics lab pic2
Thermal Science Demonstration Unit

Experimental system for studying characteristics of fuel cells

Experimental system for studying characteristics of fuel cells

The boiling heat transfer unit for studying pool boiling heat transferBoiling heat transfer unit for studying pool boiling-heat-transfer
lab_pic7Refrigeration and heat Pump Demonstration Unit Viscosity experimental set-up used to determine viscosity of different liquidsViscosity experimental set-up used to determine viscosity of different liquids
 The Pelton turbine
The Pelton turbine for fluid mechanics lab
 Convective heat transfer experimental system
Convective heat transfer experimental system
 Wind Turbine
Wind Turbine for aerodynamics lift and drag studies on airfoils and other bodies
 Gasoline  Engine Test Bed
Gasoline Engine Test Bed for measurement of the performance of gasoline engines



Computing Lab:

PACE-labPACE Team Center Lab
Twenty Five High-end HP engineering workstations
Software Unigraphics NX7.5 (CAD)
MAC. ADAMS, Altair. HyperWorks, and ANSYS (CAE)
lab_pic9Tandberg Video conference system
 PowerWall Virtual Reality System2PowerWall Virtual Reality SystemA flat, large-scale stereoscopic visualization system

Measurement Lab:

IMG_1931Keysight Oscilloscope MSOX2014A IMG_1918Planimeter (Area measurement device)
IMG_1917Dead Weight Tester for pressure gage and transducer calibration

IMG_1910

National Instruments Compact DAQ

for data acquisition

IMG_1916Vertical mass-spring-damper system

for statics/dynamic analyses

IMG_1915

Quanser Rotary Servo Base Unit

for sensor and actuator study

IMG_1914

Mass-spring-damper system

for dynamics and control experiments

IMG_1911

National Instruments ELVIS II

for mechatronics sensor system





Manufacturing Lab:

CNC Mill

HAAS CNC Milling Machine

Mill

 Webb 3VK Mill

IMG_4082Victor 1660B Lathe IMG_4080CNC Lathe with Robotic Arm
BandSaw

Wilton Bandsaw

IMG_4081Grizzly G3104 Surface Grinder
